4.8, 5.3, 5.7, 6.0, 6.2, 7.0. Ls1, Ls2, Ls3. Lq4, Lq9 Engine Ls7 Lifters

Brand

Gmc

Fitment Type

Chevrolet

Parts, Labor and machining If you got a trick or Blow Head gasket this is the same job. Engines is pull out and inspected for any other problem. Upgrade stage 2 cam or stock cam dod delete system Specifications: 1. Camshaft Compatibility: for Chevy LS-Series Engine 1997-Up Not for use with AFM/DOD Camshaft RPM Range: 2200 to 5400 RPM Camshaft Intake Valve Lift: .585" Camshaft Exhaust Valve Lift: .585" Camshaft Advertised Intake Duration: 283° Camshaft Advertised Exhaust Duration: 286° Camshaft Intake Duration at .050": 228° Camshaft Exhaust Duration at .050": 230° Camshaft Lobe Separation: 112° Camshaft Intake Centerline: 108° Camshaft Cam Gear Attachment: 3-Bolt 2. Number of Springs Per Valve: Single Outside Diameter of Outer Spring (in): 1.290 in. Spring Coil Bind Height (in): 1.140 in. Damper Spring Included: No Spring Install Load: 130lbs Spring Install Height: 1.800" Spring Open Height: 1.175" Spring Open Load: 318 lbs Spring Rate (lbs/in): 313 lbs./in. Inside Diameter of Outer Spring (in): 0.885 in. Valve Spring Style: Beehive 3. Set of 16 Elgin Roller Lifters for 1(contact info removed) Chevy/GM LS Series Factory Roller applications without Active Fuel Management. Fitment: Fits for 1(contact info removed) Trucks/SUVs 4.8L V-8 VIN-V,C,A Fits for 1(contact info removed) Trucks/SUVs 5.3L V-8 VIN-T,Z,B Fits for 1(contact info removed) 5.7L LS1 V-8 Fits for 2001-2005 5.7L LS6 V-8 Fits for 1(contact info removed) Trucks/SUVs 6.0L V-8 VIN-U,K Fits for 2005-2009 6.0L LS2 V-8 Fits for 2008-2013 6.2L LS3 V-8; without AFM Fits for 2006-2013 7.0L LS7 V-8 Also fit for Factory Roller 93-97 LT1, and 305-350 Chevy Engines. *4 putters 5/16" DIAMETER - 7.400" LENGTH - .080 WALL THICKNESS *5 M295(1(contact info removed)) Oil Pump Timing chain
