Electrical Usage Meter E-Con Single Phase KWH Meter

Model: (contact info removed)-SA KIT 100Amp, 120/208V, 1 or 2 Phase, 3 Wire supplied with (2) split-core current sensor Features: Direct-read 8-digit LCD display without multiplier displays cumulative kWh and "real-time kW load. Revenue Grade Metering Accuracy. Patented 0-2 volt output split-core current sensors promote enhanced safety and accurate remote mounting of current sensors up to 2,000 feet from the meter without power interruption. (Optional solid-core current sensors available in 100 & 200 Amp.) Parallel up to three (3) sets of current sensors for cumulative reading. Current sensor installation diagnostics. Meter can be used in the following configurations: 1-Phase, 2 Wire 2-Phase, 3 Wire For other configurations contact factory. Industrial grade JIC steel enclosure (Dim. 6 3/4" H x 5 3/16" W x 3 1/4" D) for indoor installations with 1 1/16" Knockout (3/4" conduit.) on bottom of enclosure. Padlocking hasp and mounting flanges. Maintains reading in the event of power failure. Compatible with E-Mon D-Mon accessories. Non-volatile memory. UL/CUL Listed. Certified to ANSI C12.1 and C12.16 electronic meter national accuracy standards. (+/-1% from 1% to 100% of rated load) California CTEP approved for use with solid-core current sensors. Listed by the California Energy Commission. New York City approved, Con Edison approved for RSP program.

Condition

Used (normal wear)

Model

3208100 SA KIT

Brand

E-Con
