2012 Forest River Wolf pup 17RR

Year

2012

Model

Wolf pup 17RR

Make

Forest River

Forest River Wolf Pup 17RR (also known as Cherokee/Wolf Pup 17RR toy hauler) Exterior Dimensions: Length (overall) -19 ft 9 in (237 in / 6.0 m) Width (body) - 8 ft 3 in (99 in / 2,514 mm) Height (exterior) - 9 ft 10 in (118 in / 2,997 mm) Weight & Capacity Unloaded Vehicle Weight (Dry Weight / UVW): 3,202 lbs (1,452 kg) Gross Vehicle Weight Rating (GVWR): ~5,361 lbs (deduced: 3,202 + 2,159) Cargo Carrying Capacity (CCC / Payload): 2,159 lbs (979 kg) Hitch (Tongue) Weight: 380 lbs (172 kg) Tank Capacities Fresh Water Tank: 50 gal (189 L) Gray (Sink/Shower) Tank: 31 gal (117 L) Black (Toilet) Tank: 41 gal (155 L) Propane Capacity: 9.4 gal (~40 lb) Structure & Chassis Axles: Single Brakes: Rear electric drum; no front brakes Leveling Jacks: Manual rear, electric front jack. Construction: Aluminum body; fiberglass sidewalls Tires/Wheels: 14″ wheels; spare mounted externally Interior & Layout Sleeping: Up to 5 (front double bed + convertible rear area) Slideouts: None (0) Climate Control: 13,500 BTU AC & 20,000 BTU furnace Water Heater: 6 gal propane/electric with bypass This is a compact toy hauler built for efficiency—it’s just under 20 ft long, 8 ft wide, and 9 ft 10 in tall. With a dry weight of about 3,200 lbs and payload capacity over 2,100 lbs, you’ve got decent room for gear, water, and supplies before hitting the GVWR. It rides on a single axle, has modest AC/heating, and no slide-outs. Has normal use and wear, with pitting on the front of the camper. Tear in the linoleum floor. Scratches and surface marks on cabinetry doors and shelves. stored under a cover, no leaks. All Keys/Locks work. Title in Hand.
