RSL Sound 10S MKii

Frequency Response: MKII/LFE mode (anechoic): 22-200 Hz ± 3db MKII/LFE mode (+ room gain): ~18-200 Hz ± 3db (varies with room size) Woofer: 10” 400+ watt rated woofer 4 ohm nominal Impedance Die-cast aluminum frame High-Excursion FEA optimized design motor structure 1008 low-carbon steel motor parts (T-yoke and field plate) Premium grade dual-stacked ceramic magnets Ultra-high Temp (200° C), Multi-layer Copper Voice Coil High yield fatigue-resistant Nomex™ spider Kevlar™ reinforced paper cone with full anodized aluminum dust cap High durability NBR surround High duty cycle flexible tinsel lead wire with strain relief feature Enclosure: Rear-vented Compression Guide™ tuning Integrated cross-bracing reinforcement ¾” thick MDF woofer panels Laminated 1” front woofer baffle Removable cloth grille (black / heather gray) XDR Series Amplifier: 400 watts RMS < 1% THD 1020 watts peak Selectable dual-mode DSP – LFE/Music Integrated double-precision 56-bit, 50 MIPS DSP processor Intelligent class D topology, >85% Efficiency Signal to noise ratio: >85dB Auto-ON Threshold: 3mV Auto-OFF: 20 minutes (no signal) Stand-by power consumption: ~0.5 watts Power Input: Selectable 110/230VAC 50-60Hz switch Low EMI design, CE & C-Tick compliant Line level RCA inputs and RCA pass-through signal outputs Speaker level binding post inputs Chassis ground screw Wireless Pairing Button: Integrated 2.4GHz wireless receiver compatible with RSL AT-3 & AT-4 Transmitters Crossover Frequency: 40-200 Hz variable Crossover Slope: 24 dB/oct Phase Control: 0 to 180 continuously variable Power Input: 115V, 60Hz, 230V, 50/60Hz AC Feet: Includes 4 rubber feet Dimensions with Feet: H: 15 1/2” W: 15” D: 15 3/4” Weight: 40.6 lbs Shipping Dimensions: H: 20” W: 20” D:20” Shipped Weight: 48.6 lbs Fuse: 115V (T5.0AL/250V) – 230V (T2.5.0AL/250V)
