Rheem Air Handler Control Board 48P21-111-01, 47-102077-04 (contact info removed)3

Type

Controls & Circuit boards

Brand

Rheem

This Rheem Air Handler Control Board, model 47-102077-04, is a powerful and efficient control unit for your HVAC system. Designed with a voltage of 24V and amperage of 3A, this control board is compatible with Rheem, Ruud, Weatherking, and Corsair systems. It is suitable for use with central furnace, central air conditioner, air conditioner split system, and heat pump split system. The control board's dimensions are 4 1/2 in length, 2 1/4 in width, and 1 1/2" thickness. It is hardwired and features a 1 phase power phase. This item is a reliable and durable addition to your HVAC system and is made by Rheem, a trusted brand in the industry. WHITE-RODGERS 48P21-811 AIR HANDLER CONTROL BOARD, REPLACEMENT FOR RHEEM/RUUD FAST AND EASY DIRECT OEM REPLACEMENT FOR RHEEM/RUUD APPLICATIONS Rheem single stage air handler control designed for PSC blower motors Fast drop-in OEM mounting and wiring Multiple system voltages provides replacement of three dedicated-voltage Rheem kits Includes wiring harness that allows replacement of legacy units SPECIFICATIONS Family Brands of Equipment: Rheem Direct Replacement Stages: Single Line Voltage: 240 Vac Inducer Motor/Blower Motor: PSC Mounting Options: Standoff Ambient Operating Temperature: -40 to 175°F (-40 to 80°C) Humidity Range: 5% to 95% relative humidity (non-condensing) CROSS REFERENCE Rheem/RUUD Brands: 47-100436-01, 47-100436-04, 47-100436-04-03, 47-100436-05, 47-100436-84A (115V Kit), 47-100436-84D (460V Kit), 47-100436-84J (208/240V Kit), 47-102077-04, 47-102077-04-00, 1005-173A, 1005-83-1722A, 1139-83-160A White-Rodgers: 48P21-111, 48P21-811
