Tiny Home On Wheels

Year

2024

The Cottage family model has 5 people capacity (1 sofa bed full size, 1 loft full and 1 loft individual) makes the perfect guest house or mother-in-law room. It has everything your guests will need to be fully self-sufficient in their own independent space while still being close to your home for a visit key details HOUSE LENGTH (EXTERIOR) 20’ EXTERIOR WIDTH 8’ EXTERIOR HEIGHT 13’6” TOTAL SQ FT 161 LOFT DIMENSIONS 7’ X 4’ LOFT HEIGHT (at low side) 36” HEIGHT UNDER LOFTS 6’4” SLEEPS 3 Overview 20 ft tiny home on wheels. Certified RV by NOAH. Dimensions 8′ W x 20′ L x 13.6′ H Build Platform Bumper pull with 5,000 lb each double axles. Hand built chassis, thick gauge steel, trailer brakes, highway lighting, DOT approved. Roof Gulf-Rib 29g metal roof. Shed (single-pitch) roofline. Sheathing 1/2 in OSB with ice&water weather shield Siding LP SmartSide painted lap siding with hardi board and batten trim and sealed and stained pine tongue and groove accents (custom colors available). Power hookup 50 amp hookup for electrical service to home. Exterior outlet. Water system Fresh water hose inlet. Hot water heater Electric tankless instant hot water heater. Heat / Cooling Ductless mini split A/C and heat pump, 12,000 BTU. Walls Painted drywall or painted shiplap (paint & stain options available). Ceiling Stained pine tongue & groove (paint & stain options available). Option to upgrade to painted shiplap. Subfloor 2x6 framed R19 insulated subfloor with 3/4” plywood. Insulation R13 fiberglass roll insulation in walls. R19 fiberglass roll insulation in floor and ceiling. Flooring Pro grade waterproof vinyl in lofts, kitchen, and living space (color options available). Porcelain tile in bathroom. Doors Fiberglass door, full glass with built in blinds. Windows Vinyl double paned impact resistant windows. Lighting Slim profile LED ceiling lights. Exterior light sconce. Bathroom 36″ x 34″ shower pan with full tile surround. Mini sink mounted to wall. Custom pine swing door. Standard porcelain gravity flush toilet. Connections (vent/outlet) for alternative toilet or composting toilet also available. Kitchen Closed lower cabinets painted; open upper shelving. Butcher block counter with drop-in stainless or composite sink. Brushed nickel, oil rubbed bronze, or black faucet and cabinet hardware (other finish options available). Appliances 2-burner electric cooktop infrared stove flush mount with butcher block counters. 3.1 cubic foot stainless steel mini fridge with separate freezer compartment with option for larger fridge. Living Area 5’ built in seating area. Loft & Access Master sleeping area on main level fits queen sized bed. 7x3.3’ loft with ladder access. Black metal railings. Warranty One month limited warranty on workmanship.
