$400

Beckett SDC oil Burner

Posted in Peoria, AZ

Listed in categories:

Sold by

FN

FN

Joined Jan 2016

|

(71) offer up reviews

Chat securely on the app

Beckett SDC oil Burner

Additional images

Description

Burner Igniter Pump Functions great, used on heater for a year. We upgraded to larger burner and this no longer was needed. Voltages Rated Voltage: 13.5V or 27V (Nominal Charging System Voltage) Reference Voltage: 12V or 24V (Battery Discharge Voltage) Capacity at Rated Voltage 1.75 to 5.50 GPH 245,000 to 770,000 BTU/hr input Capacity at Reference Voltage 1.75 to 5.00 GPH 245,000 to 770,000 BTU/hr input Fuels U.S. – No. 1 or No. 2 diesel fuel or kerosene. No. 1 or No. 2 heating oil (ASTM D396) only. Fuel Unit Single stage or two stage Ambient Operating Temperature +32°F (0°C) Minimum +115°F (+46°C) Maximum Electrical Characteristics Motor: 13.5 VDC, 1/4HP, 3450 RPM, 18.75 Amps (max.), NEMA M-flange, rotation CCW when facing shaft end Power Supply: 13.5 VDC Ignition: 20KVpk 28 mA interrupted duty OR optional continuous duty, solid state ignition Operating Load: 25 amps (Actual draw could be less depending on application) Alternated Voltages or Frequency: Consult Customer Service Dimensions (standard) Height: 13-5/8″ Width: 15-3/8″ Depth: 8-1/

All content is available to screen readers from the outset. The See more button is for visual users only to expose content incrementally that is already available to you

Details

Condition

Used (normal wear)
