Flexible Power SOOW Cord 100feet 600 Volts
Posted in Los Angeles, CA
Listed in categories:
Chat securely on the app
Additional images
Description
Conductor: * Fully annealed stranded bare copper per ASTM B-174. Insulation: * Color coded 90° C EPDM Jacket * Black thermosetting. * Temperature Range: -40° C to +90° C. * Voltage Rating: 600 volts. Application * Portable tools and equipment. * Portable appliances. * Small motors and associated machinery. Features * Excellent resistance to oil and moisture. * Good tensile strength, elongation and aging characteristics. * High flexibility. * Excellent abrasion resistance. * Water resistant. Specifications Size (AWG/MCM) 8 No. of Conductors 3 Strands 133/29 Nominal Insualtion Thickness (inches) 0.047 Nominal Jacket Thickness (inches) 0.095 Nominal O.D (inches) 0.760 Current (Amps) 40 Nominal Weight (LBS/MFT) 491 Voltage Rating (Volts) 600 Notes *No. 8 AWG and larger not UL listed or CSA certified rated type SO only. We can offer UL & CSA on No. 8 AWG and larger. Check factory for availability and pricing. Special Order. Temperature Rating 90 °C Conductor Color Code Cond. 1- Black, Cond. 2- White, Cond. 3- Green. Order Carefully No Returns.
Details
Condition
New
